Inconel 600 is a nickel-chromium alloy with excellent resistance to high temperatures and corrosion, used in furnace components, heat exchangers, and nuclear applications.
Element | Content (%) |
Nickel (Ni) | ≥ 72.0 |
Chromium (Cr) | 14.0 – 17.0 |
Iron (Fe) | 6.0 – 10.0 |
Manganese (Mn) | ≤ 1.00 |
Silicon (Si) | ≤ 0.50 |
Carbon (C) | ≤ 0.15 |
Sulfur (S) | ≤ 0.015 |
Property | Value (Typical) | Unit | Condition |
Tensile Strength (Ultimate) | ≥ 550 | MPa | Annealed |
Yield Strength (0.2% Offset) | ≥ 240 | MPa | Annealed |
Elongation (in 50 mm) | ≥ 30 | % | ASTM B168 |
Hardness (Brinell) | ≤ 155 | HB | |
Density | 8.47 | g/cm³ | Room Temp |
Melting Range | 1370 – 1430 | °C | |
Modulus of Elasticity | ~207 | GPa | Room Temp |
Category | Standard Code | Description |
Pipe | ASTM B167 / ASME SB167 | Seamless Inconel 600 pipe for high-temperature applications |
Tube | ASTM B163 / ASME SB163 | Seamless Inconel 600 heat-exchanger tubes |
Fittings | ASTM B366 / ASME SB366 | Inconel 600 wrought fittings |
